  • 10G Transceiver Solutions

    Sopto provides a series of 10G transceiver modules, including SFP+, XFP, BIDI SFP+, BIDI XFP, CWDM/DWDM SFP+; They are designed for using in 10G Ethernet, 10G Fiber Channel, SONET/SDH OC-192/STM-64, and OTN OTU2e links. Digital diagnostics functions.

                     [email protected]

    10G SFP+ Transceiver.png

    10G SFP+ transceiver are multi-purpose optical modules for 10Gbit/s data transmission applications at 850nm, 1310nm and 1550nm. The transceivers are ideally suited for datacom and storage area network (SAN/NAS) applications based on the IEEE 802.3ae and Fibre Channel standards, Fiber Channel 10G, 8.5G, 4.25G, 2.125G, 1.0625G, 10G BASE-SW/SR/LRM/LR/ER, 1000 Base-SX Ethernet.

    Part No.

    Description

    Applications

    Details

    SPT-P13TG-IR

    10Gb/s 2km SFP+ Transceiver Hot Pluggable, Duplex LC, +3.3V, 1310nm FP-LD, Single mode ,Temperature Range: 0~ 70°C.

    ● 10GBASE-LR/LW Ethernet

    ●  SONET OC-192 / SDH

    ●  10G Fibre Channel

    PDF

    SPT-P13TG-LR(S)

    10Gbps SFP+ Optical Transceiver,10km or 20km Reach, Duplex LC, 1310nm DFB transmitter, Single mode, Operating case temperature:  Standard:  0 to +70°C, Industrial: -40 to +85°C.

    PDF

    SPT-P31TG-LRM

    10Gb/s 220m SFP+ Transceiver, Hot Pluggable, Duplex LC, +3.3V, 1310nm FP-LD, Multi mode , Temperature Range: 0~ 70°C.

    ● 10GBASE-LRM Ethernet

    ● Legacy FDDI multimode links

    PDF

    SPT-P55TG-ER(S)

    10Gbps SFP+ Optical Transceiver, 40km or 60km Reach, Duplex LC, 1550nm DFB or Cooled EML transmitter,  Temperature Range: 0~ 70°C.

    ● 10GBASE-ER/EW (with/without FEC)

    ● 10G Fiber Channel (with/without FEC)

    PDF

    SPT-P55TG-ZR

    10Gbps SFP+ Optical Transceiver, 80km Reach,  Duplex LC, 1550nm, 0 ~ +70ºC EML laser .

    ● 10G Ethernet

    ● 10G Fiber Channel (with/without FEC)

    PDF

    SPT-P55TG-ZR+

    10Gb/s 100km SFP+ Transceiver, Hot Pluggable, Duplex LC, +3.3V, 1550nm EML&APD, Single mode, lTemperature Range: 0~ 70°C.

    ● 10GBASE-ZR/ZW Ethernet

    ● SONET OC-192 / SDH

    ● 10G Fiber channel

    PDF

    SPT-P55TG-ZR++

    10Gb/s 120km SFP+ Transceiver,Hot Pluggable Duplex LC, +3.3V, 1550nm CML&APD Single mode, Temperature Range: 0~70℃

    PDF

    SPT-P85TG-SR

    10Gbps SFP+ Optical Transceiver, 300m Reach, Hot Pluggable ,Duplex LC, 850nm VCSEL transmitter, Multi mode, Operating case temperature: 0 to 70℃.

    ● 10GBASE-SR at 10.3125Gbps

    ● 10GBASE-SW at 9.953Gbps

    ● Other optical links

    PDF

    10G SFP+ Modules.png

    Type 1:10G SFP+ Transceiver


    10G XFP transceiver.png

    10G XFP transceiver is a high performance, cost effective modules for serial optical data communications applications specified for signal rates of 9.95 Gb/s to 11.3 Gb/s. It is fully compliant to XFP MSA Rev 4.5. The modules are designed for single or multi mode fiber and operates at a nominal wavelength of 850/1310/1550 nm, XFP SR, XFP LR, XFP ER and XFP ZR. The transmitter section incorporates uncooled directly modulated 1310 nm distributed feedback laser (DFB) or EML cooled laser 1550nm. The receiver section uses PIN photodetector for low dark current and excellent responsivity or APD high sensitivity receiver.

    Part No.

    Description

    Applications

    Details

    SPT-X13TG-IR

    10Gb/s 2km XFP Transceiver, Hot Pluggable, Duplex LC, 1310nm, FP LD, Single mode fiber, Temperature range 0°C to 70°C.

    ● 10GBASE-IR Ethernet

    ● SONET OC-192 /SDH

    ● 1200-SM-LL-L 10G Fibre Channel

     Other optical links

    PDF

    SPT-X13TG-LR(S)

    10Gbps XFP Optical Transceiver, 10km or 20km Reach, Hot pluggable, Duplex LC, 1310nm DFB, Single mode fiber, Temperature range 0°C to 70°C .

    ● 10GBASE-LR/LW Ethernet

    ● SONET OC-192 /SDH

    ● 1200-SM-LL-L 10G Fibre Channel

     Other optical links

    PDF

    SPT-X31TG-LRM

    10Gb/s 220m XFP Transceiver, Hot Pluggable, Duplex LC, 1310nm, FP LD, Multi mode, Temperature range 0°C to 70°C.

    ● 10GBASE-LRM Ethernet

    ● Legacy FDDI multimode links

     Other optical links

    PDF

    SPT-X55TG-ER(S)

    10Gbps XFP Optical Transceiver, 40km or 60km Reach, Duplex LC, 1550nm DFB or Cooled EML laser,Multi mode,  Temperature range 0ºC ~ +70ºC

    ● SONET(OC-192)/SDH(STM64) line card

    ● 10GE Ethernet switches and routers

    ● 10GE Core-routers

    ● 10GE Storage

    ● Inter Rack Connection

     Other high speed data connections

    PDF

    SPT-X55TG-ZR

    10Gb/s 80km XFP Transceiver, Hot Pluggable, Duplex LC, 1550nm, EML&APD, Single mode, Temperature range 0°C to 70°C

    ● 10GBASE-ZR/ZW Ethernet

    ● SONET OC-192 / SDH STM-64 ITU-T G.959.1 P1L1-2D2

    ● 80km 10G FC

     Other optical links

    PDF

    SPT-X55TG-ZR+

    10Gb/s 100km XFP Transceiver, Hot Pluggable, Duplex LC, 1550nm, EML&APD, Single mode, Temperature range 0°C to 70°C.

    ● 10GBASE-ZR/ZW Ethernet

    ● SONET OC-192 / SDH STM-64 ITU-T G.959.1 P1L1-2D2

    ●  100km 10G FC

    ● Other optical links

    PDF

    SPT-X55TG-ZR++

    10Gb/s 120km XFP Transceiver, Hot Pluggable Duplex LC 1550nm CML&APD Single mode, Temperature range 0℃ to 70℃.

    ● 10GBASE-ZR/ZW Ethernet

    ● SONET OC-192 / SDH STM-64 ITU-T G.959.1 P1L1-2D2

    ● 120km 10G FC

     Other optical links

    PDF

    SPT-X85TG-SR

    10Gbps XFP Optical Transceiver, 300m Reach, duplex LC, 850nm VCSEL laser, Temperature range: 0℃ to +70℃.

    ● 10GBASE-SR/SW 10G Ethernet

    ● 1200-Mx-SN-I 10G Fiber Channel

     Other optical links

    PDF


    10G XFP Modules.png


    Type 2:10G XFP Transceiver


    10G BIDI SFP+ Transceiver.png

    10G BIDI SFP+ transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by usually using 1330(1270nm) transmitter and 1270(1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330(1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270(1330) nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

    Part No.

    Description

    Applications

    Details

    SPT-PB2733TG-L10

    10G BIDI SFP+ Transceiver,1270nm TX/1330nm RX, 10Gbps, 10km, LC,0ºC ~ +70ºC, with DDM

    ● 10GBASE-LR at 10.3125 Gb/s

    ● 10GBASE-LW at 9.953 Gb/s

    ● Other Optical Links

    PDF

    SPT-PB3327TG-L10

    10G BIDI SFP+ Transceiver,1330nm TX/1270nm RX, 10Gbps, 10km,LC, 0ºC ~ +70ºC, with DDM

    SPT-PB2733TG-L20

    10G BIDI SFP+ Transceiver 1270nm TX/1330nm RX, 10Gbps, 20km,LC, 0ºC ~ +70ºC, with DDM

     10GBASE-LR at 10.3125 Gb/s

    ● 10GBASE-LW at 9.953 Gb/s

    ● Other Optical Links

    PDF

    SPT-PB3327TG-L20

    10G BIDI SFP+ Transceiver 1330nm TX/1270nm RX, 10Gbps, 20km,LC,0ºC ~ +70ºC, with DDM

    SPT-PB2733TG-L40

    10G BIDI SFP+ Transceiver 1270nm TX/1330nm RX, 10Gbps, 40km, LC,0ºC ~ +70ºC, with DDM

    ● 10GBASE-LR at 10.3125 Gb/s

    ● 10GBASE-LW at 9.953 Gb/s

    ● Other Optical Links

    PDF

    SPT-PB3327TG-L40

    10G BIDI SFP+ Transceiver 1330nm TX/1270nm RX, 10Gbps, 40km,LC, 0ºC ~ +70ºC, with DDM

    SPT-PB2733TG-L60

    10G BIDI SFP+ Transceiver 1270nm TX/1330nm RX, 10Gbps, 60km, LC,0ºC ~ +70ºC, with DDM

     10GBASE-LR at 10.3125 Gb/s

    ● 10GBASE-LW at 9.953 Gb/s

    ● Other Optical Links

    PDF

    SPT-PB3327TG-L60

    10G BIDI SFP+ Transceiver 1330nm TX/1270nm RX, 10Gbps, 60km, LC,0ºC ~ +70ºC, with DDM

    SPT-PB47TG-L80

    10G BIDI SFP+ Transceiver 1490nm TX/1570nm RX, 10Gbps, 80km, LC,0ºC ~ +70ºC, with DDM

    ● 10GBASE-LR at 10.3125 Gb/s

    ● 10GBASE-LW at 9.953 Gb/s

    ● Other Optical Links

    PDF

    SPT-PB47TG-L80

    10G BIDI SFP+ Transceiver 1570nm TX/1490nm RX, 10Gbps, 80km, LC,0ºC ~ +70ºC, with DDM


    10G BIDI SFP+.png


    Type 3:10G BIDI SFP+ Transceiver


    10G BIDI XFP Transceiver.png

    10G BIDI XFP transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by using 1330(1270nm) transmitter and 1270(1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330(1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270(1330) nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.

    Part No.

    Description

    Applications

    Details

    SPT-XB2733TG-L10

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 10km with DDM Commercial Temperature

    ● 10GBASE-LR/LW Ethernet

    ● SONET OC-192 /SDH

    ● 1200-SM-LL-L 10G Fibre Channel

    PDF

    SPT-XB3327TG-L10

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 10km with DDM Commercial Temperature

    SPT-XB2733TG-L10T

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 10km with DDM Industrial Temperature

    SPT-XB3327TG-L10T

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 10km with DDM Industrial Temperature

    SPT-XB2733TG-L20

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 20km with DDM Commercial Temperature

    ● 10GBASE-LR/LW Ethernet

    ● SONET OC-192 /SDH

     1200-SM-LL-L 10G Fibre Channel

    PDF

    SPT-XB3327TG-L20

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 20km with DDM Commercial Temperature

    SPT-XB2733TG-L20T

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 20km with DDM Industrial Temperature

    SPT-XB3327TG-L20T

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 20km with DDM Industrial Temperature

    SPT-XB2733TG-L40

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 40km with DDM Commercial Temperature

    ● 10GBASE-LR/LW Ethernet

    ● SONET OC-192 /SDH

     1200-SM-LL-L 10G Fibre Channel

    PDF

    SPT-XB3327TG-L40

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 40km with DDM Commercial Temperature

    SPT-XB2733TG-L40T

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 40km with DDM Industrial Temperature

    SPT-XB3327TG-L40T

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 40km with DDM Industrial Temperature

    SPT-XB2733TG-L60

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 60km with DDM Commercial Temperature

    ● 10GBASE-LR/LW Ethernet

    ● SONET OC-192 /SDH

     1200-SM-LL-L 10G Fibre Channel

    PDF


    SPT-XB3327TG-L60

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 60km with DDM Commercial Temperature

    SPT-XB2733TG-L60T

    Transceiver XFP Single Fiber BIDI 1270nmTx/1330nmRx 10G LC Interface 60km with DDM Industrial Temperature

    SPT-XB3327TG-L60T

    Transceiver XFP Single Fiber BIDI 1330nmTx/1270nmRx 10G LC Interface 60km with DDM Industrial Temperature

    SPT-XB47TG-L80

    Transceiver XFP Single Fiber BIDI 1490nmTx/1570nmRx 10G LC  Connector 80km with DDM  Commercial Temperature

    ● 10GBASE-ZR/ZW Ethernet

    ● SONET OC-192 /SDH

     10G Fibre Channel

    PDF

    SPT-XB74TG-L80

    Transceiver XFP Single Fiber BIDI 1570nmTx/1490nmRx 10G LC  Connector 80km with DDM  Commercial Temperature


    10G BIDI XFP.png

    Type 4:10G BIDI XFP Transceiver


    All 10G optical transceivers modules are RoHS compliant and could be 100% compatible with branding equipment, such as Cisco, Extreme, Juniper, HP, H3C, Linksys, Huawei, Alcatel-Lucent, Foundry, Nortel, Force10 etc.If you want to know more or get price about the exact information of the specified transceiver, Please Contact Us.
